Navtronicx Thermologs

Device Specifications

  • Wi-Fi: 2.4 GHz IEEE 802.11 b/g/n.
  • Security: WPA2 secured connectivity.
  • Protocol: Secure MQTT communication between field device and cloud platform.
  • Cloud Integration: Native support for cloud-based data storage and visualization.
  • Primary Power: 5V DC via USB-C connector.
  • Battery Type: Removable built-in Li-Ion 18650 cell.
  • Backup Duration: Up to 12 hours of UPS operation under normal load.
  • Charging: USB-C charging interface with built-in charge management.
  • Sensor Type: Industrial-grade PT100 RTD (Resistance Temperature Detector).
  • Sensor Input: 3-wire or 4-wire configuration (optional).
  • Measurement Range: –200°C to +600°C (depending on sensor type)
  • Accuracy: ±0.1°C typical (excluding sensor tolerance)
  • Display: 1.14-inch full-color IPS LCD display.
  • Resolution: 135 × 240 pixels (approx.)
  • Functions Displayed:
    • Real-time temperature readings.
    • Battery level and connectivity status.
    • Device name and sampling interval.
  • Sampling Rate: Adjustable, starting from 1 sample per second.
  • Data Storage: Cloud-based with time-series database architecture.
  • User Management:
    • Self-service creation of user accounts.
    • Easy addition and deletion of devices.
    • Secure authentication and role-based access.
  • Data Sharing: Cross-account data sharing enabled.
  • Visualization:
    • Live data dashboard with real-time updates.
    • Historical trend visualization and export options.
  • Enclosure: Compact and robust design suitable for industrial environments.
  • Mounting Options: Wall-mount.
  • Dimensions: 90mm x 80mm x 25 mm.
  • Weight: 150g.
  • Operating Temperature: 0°C to +60°C (device)
  • Storage Temperature: –20°C to +70°C
  • Relative Humidity: 10% to 90% (non-condensing)
  • Wi-Fi Certification: IEEE 802.11 compliant.
  • Safety: Overcharge, overcurrent, and reverse-polarity protection.
  • Firmware Update: OTA (Over-the-Air) capable.
  • Food and beverage process monitoring.
  • Pharmaceutical storage and cold-chain tracking.
  • Laboratory temperature logging.
  • Industrial process control.
  • Smart facility environmental monitoring.

Security

ThermoLogs is designed with a security-first architecture to ensure the integrity, confidentiality, and privacy of all recorded data. The device does not contain any audio, video, location tracking, or personal data collection capabilities, making it safe for installation across regulated, privacy-sensitive environments such as laboratories, healthcare facilities, pharmaceuticals, and food manufacturing sites.

Security Illustration
  • No Microphones or Cameras – The device has no built-in microphones, cameras, or audio/video capture modules.
  • No GPS or Location Tracking – ThermoLogs does not capture or transmit any location metadata.
  • Local Data Protection – All device-stored data is minimal and encrypted before transmission.
  • Secure Cloud Storage – Data is stored in a secure cloud environment using industry-standard encryption
  • Role-Based Access Control (RBAC) – User roles, device ownership, and sharing permissions ensure that only authorized users can access data.
  • Audit Logs – All major actions (device binding, sharing, access) are logged for accountability.
  • No Personal Data Collection – ThermoLogs does not collect names, addresses, biometric data, voice recordings, or any PII.
  • User-Controlled Sharing – Device data can only be shared by the registered owner via explicit email invitation.
